測量范圍Capacity

kg

 輸出靈敏度Rated Output

3．0±0.010

mV/V

 非線性Linear

±0.03

%F.S

 滯后Hysteresis

±0.03

%F.S

 重復性Reapeatability

±0.01

%F.S

 蠕變Creep

±0.03

%F.S

 零點輸出Zero Balance

≤±1.0

%F.S

 溫度補償范圍 Conpensated Temperature Range

室溫～+60

℃

 零點溫度補償系數Temperature Effect On Zero

±0.03

%F.S/10 ℃

 額定輸出溫度系數 Temperature Effect On Output

±0.03

%F.S/10 ℃

 供橋電壓 Excitation Voltage

10V

AC/DC

 絕緣電阻Insulation Resistence

≥5000

MΩ/100VDC

 輸入電阻 Input Resistence

770±8

Ω

 輸出電阻Output Resistence

700±2

Ω

 允許過載系數Safe Overload

120

%F.S

電纜連接方式Cable Connection

信號輸出Singal Output： 黃:Yellow (+) 黑:Black (－)

供橋電壓Excitation Voltage： 紅Red: (+) 綠Green： （－）
